Buyers near a busy campus often shop for several small lots at once, then plan to treat them as one site. An ALTA Survey pulls those separate lots into a single measured drawing, so the whole purchase can be reviewed as one piece of ground. Each lot arrives with its own deed, its own history and its own recorded rights, and those parts rarely line up in a tidy way. Most of the hard work starts long before a crew sets a single stake in the dirt.

Building One Survey From Multiple Legal Descriptions

The surveyor gathers every deed in the group, plus any recorded plat that created the lots in the first place. Descriptions near an older campus can be a century old, and some of them point to things that vanished long ago, like a fence corner or a road that has since been widened. Each description gets drawn on its own first, so the crew can compare the pieces one at a time instead of guessing how they fit.

Once all the parcels sit on the same sheet, gaps and overlaps show up fast. Two neighboring deeds may both claim the same three feet of ground, or a thin strip between them may belong to neither lot on paper. Field measurements then confirm which corner markers still exist and which ones the crew has to rebuild from other evidence.

A single combined description usually comes later, written by an attorney and checked against the survey math. That new description only works if the outer line of the whole site closes correctly. The survey supplies the bearings and distances that make the writing possible.

Identifying Internal Lines That Still Carry Legal Importance

Owning every lot on a block does not erase the lines between them. Those old boundaries often appear in title exceptions, and the rights tied to them can survive a change in ownership. A utility easement written along a former side line stays exactly where it was written, no matter who holds the deeds today.

Deed restrictions work the same way. A rule recorded against one parcel may limit height, use or setbacks on that one piece of ground while the rest of the site stays free of it. The survey plots those interior conditions so the design team can see where the invisible rules sit before anyone draws a building.

Examining Shared Parking and Circulation Arrangements

Small properties near a campus tend to share driveways, curb cuts and back lots, because the individual parcels were always too tight to work alone. Some of those arrangements rest on recorded agreements with real legal weight. Others grew out of decades of neighborly habit and have nothing behind them on paper, which becomes a problem the moment a lender reads the file.

The survey shows where cars actually enter, turn and leave today, then sets that pattern next to what the title documents allow. A drive aisle that crosses a neighbor’s land without a recorded right is worth solving before closing rather than after the first concrete truck shows up.

Locating Improvements That Straddle the Proposed Assemblage

Buildings on tight lots have a habit of leaning across lines. The crew measures and maps the improvements that touch or cross the former boundaries, and the common ones include:

• building corners, awnings and roof overhangs that reach past a lot edge
• pavement, curbs and parking stalls that spill from one lot onto the next
• signs, poles and their foundations set close to a shared line
• retaining walls and fences that follow use rather than the deed
• dumpster pads, service doors and utility hookups that lean on the property next door

Each one gets located with real measurements instead of a general note. A wall sitting eight inches past a line tells the buyer something very different from a wall sitting eight feet past it. Only measured data separates the two, and only measured data holds up when a title officer starts asking questions.

Supporting a Unified Development and Financing Plan

The finished drawing gives everyone at the table the same reference. A lender writing the loan, a title company writing the policy, an architect placing a new building and an attorney drafting the combined description all work from one set of measurements and one set of plotted exceptions. Questions get settled against the drawing instead of against memory.

That shared reference also shortens the arguing stage of a project. A title exception can sound alarming in writing, then plot harmlessly along a rear alley, and the drawing proves it in seconds. When an exception runs straight through the proposed building pad, the team finds out early enough to redesign rather than late enough to lose real money.

Frequently Asked Questions

Can one ALTA Survey cover several parcels being purchased together?

Yes. A surveyor can map a group of neighboring parcels on one drawing, showing each original description along with the outer limits of the combined site. Title commitments usually cover the parcels as a package, and the survey follows that same structure so the two documents match each other.

Do internal parcel lines disappear automatically after one buyer owns every tract?

No. Common ownership does not merge the lots by itself. The recorded lines stay in place until a legal step such as a replat or a lot combination removes them. Easements and restrictions tied to those lines can also outlive the purchase, so the survey keeps showing them.

Should the parcels be legally combined before or after the commercial closing?

That call belongs to the buyer, the attorney and the local jurisdiction rather than the surveyor. Many buyers close first and combine the lots afterward, since lenders and title underwriters usually want the survey and the title work finished before a replat moves ahead. The survey supports either order by recording current conditions the same way.
